How long is the Galeon Yachts 400 FLY?

The Galeon Yachts 400 FLY has a length overall (LOA) of 40.93 feet (12.48 meters).

How many cabins does the Galeon Yachts 400 FLY have?

The Galeon Yachts 400 FLY has 2 cabins, accommodating up to 12 guests.

What is the top speed of the Galeon Yachts 400 FLY?

The Galeon Yachts 400 FLY has a maximum speed of 28 knots and a cruising speed of 25 knots.

What is the range of the Galeon Yachts 400 FLY?

The Galeon Yachts 400 FLY has a cruising range of approximately 300 nautical miles.

What is the fuel capacity of the Galeon Yachts 400 FLY?

The Galeon Yachts 400 FLY has a fuel capacity of 1000 litres.

79 photos

Galeon Yachts

400 FLY

Name: Galeon Yachts 400 FLY
Brand: Galeon Yachts

2020 – Present

40.93ftLOA

12Guests

2Cabins

28ktsMax Kts

Gallery

Specifications

Manufacturer Verified

41 ft

Length Overall

28 kts

Max Speed

1000 L

Fuel Capacity

Cabins

450 L

Fresh Water

41 ft

Length Overall

28 kts

Max Speed

1000 L

Fuel Capacity

Cabins

450 L

Fresh Water

Vessel Dimensions

Beam

13.0 ft

Draft

3.0 ft

Beam

13.0 ft

Draft

3.0 ft

Units:

Dimensions

Beam

13.0 ft

Draft

3.0 ft

Displacement

14.6 t

Performance

Max Speed

28 kts

Cruising Speed

25 kts

Range

300 nm

Range Note

10 knots

Propulsion

Engine Count

Engine Power

2x 440 HP

Hull Material

Fiberglass

Superstructure

GRP

Accommodation

Guests

Cabins

Heads

2 guest, 0 crew

Tanks

Fuel Capacity

1000 L

Fresh Water

450 L

Black Water

150 L

Design Credits

Exterior Designer

Tony Castro Yacht Design

Interior Designer

Galeon

Naval Architect

Tony Castro Yacht Design

Deck Plans & Layouts

Deck plans for this model are not yet in our database.

Know this vessel? Help us build the knowledge base.

Propulsion & Systems

Volvo Penta D6-440

Twin engine configuration

SHAFTDIESELEU RCD Stage II, IMO NOx Tier II, EPA Tier 3, China II, BSO II

Displacement: 5.5
Cylinders: 6

Navigation & Electronics

Volvo Electronic Vessel Control (EVC) SystemNavigation lightsCompassSpotlight, remote-controlledHorn, electricVolvo Volvo 7 inch digital Electronic Vessel Control panel

Safety

Automatic/manual fire extinguishing systemBilge pump high water alarmFire system monitorBilge pumps, automatic electric×2

Entertainment & AV

Fusion Stereo, Fusion 12V AM/FM with bluetooth and two speakersStereo, remote control

Galley & Appliances

Cooktop 240V two-burner inductionMicrowave ovenRefrigerator/Freezer 45 L/150 LDual stainless steel grill and sink with chrome faucet and Corian cover

Climate Control

Dometic MarineAir 40,000 BTU

Other

Corian countertopsHelm seat, double-wide upholstered sofa with armrestsFlooring, molded non-skid (bow and side deck)

Generator

Fisher Panda 12 kW

Communication

Raymarine Axiom 12+Raymarine Raymarine VHF Ray91 AIS and VHF antenna with repeater on flybridgeRaymarine EV-1 ACU200×2

Anchor & Windlass

Galvanized anchor 44 LB (20 KG) with 197 ft (60 M) of 5/16 inch (8 MM) galvanized chain with leash protectionReversible electric anchor winchAnchor roller
