Galeon Yachts 510 SKY
39 photos

Galeon Yachts

510 SKY

2017 – 2024

53.17ftLOA
6Guests
3Cabins
30ktsMax Kts

Specifications

Manufacturer Verified

53 ft

Length Overall

30 kts

Max Speed

1800 L

Fuel Capacity

3

Cabins

650 L

Fresh Water

Vessel Dimensions

WL53.2 ftLOA14.5 ftBeam4.6 ftDraft

Beam

14.5 ft

Draft

4.6 ft

Units:
Dimensions

Beam

14.5 ft

Draft

4.6 ft

Displacement

26.5 t

Performance

Max Speed

30 kts

Cruising Speed

25 kts

Range

418 nm

Range Note

8 knots

Propulsion

Engine Count

2

Engine Power

Twin Volvo Penta D11-670 (T-670 hp - 493 kw)

Hull Material

Fiberglass

Superstructure

GRP

Accommodation

Guests

6

Cabins

3

Heads

2 guest, 1 crew

Tanks

Fuel Capacity

1800 L

Fresh Water

650 L

Black Water

240 L

Design Credits

Exterior Designer

Tony Castro Yacht Design

Interior Designer

Galeon

Naval Architect

Tony Castro Yacht Design

Deck Plans & Layouts

1×
Deck plan

Propulsion & Systems

Volvo Penta D11-670

Volvo Penta D11-670

Twin engine configuration

SHAFTDIESELIMO NOx/EU Stage II/EPA Tier 3
Cylinders
6
Volvo Penta D11-725

Volvo Penta D11-725

Twin engine configuration

SHAFTDIESELIMO Tier II
Displacement
10.8
Cylinders
6
Volvo Penta D8-550

Volvo Penta D8-550

Twin engine configuration

SHAFTDIESELEPA Tier 3, IMO Tier II, China II, EU RCD
Displacement
7.7
Cylinders
6

Navigation & Electronics

Volvo Penta Electronic Vessel Control (EVC) panelStation instruments and controlsCompassHelm seat rotating doublewide with wood footrestCupholderSteering wheel exclusive GaleonOutlets USB

Safety

Automatic/manual fire extinguishing systemFire system monitorEngine ignition panelTrim tab control panelDual lever control EVCCarbon monoxide detector×3High water alarm - bilge (2)×2

Entertainment & AV

TV LED 32" with Blu-ray player in master cabinElectric sliding TV LED 43" with Blu-ray player in salon

Galley & Appliances

Cooktop 240V two-burner inductionCorian worktop with ceramic bowl and chrome faucetRefrigerator/freezer (4.6 ft/130 L)Refrigerator 240V drawer (2.5 ft/65 L)

Climate Control

Air Conditioning System Condaria Chilled water (65,000 BTU) - 240V

Mechanical & Systems

V-Drive transmission×2Propeller shafts (stainless steel)×2Propellers and rudder (bronze)×2

Other

Foldable aft balconies and sliding openable aft side windowsConvertible bar area in side cockpitWaterproof wood look floor in salonCarpets on floor in salon and galleyFiberglass lowerable table in aft cockpitUnderwater LED lights (6) - port (2), starboard (2), transom (2)×6TV LED 24" in bow cabinSoundbar system in salonGrill on rotating seatKenyon cooktop in galley to be 4 burnerUpgraded Magnum Open radar antenna 48"Filled sheet setRaymarinie Chartplotter/FF 1x Axiom 12+ RV-US and 1x Axiom 12i with transducer B744V and digital radar Quantum RD424 HDRaymarine VHF Ray91 AIS and VHF antenna with repeater on skydeckRaymarine autopilot Evolution DBW with 2x P70RS control head EV2 sensor core EV2 cabling kitAdditional Raymarine Chartplotter 1x Axiom 12+ on main stationHydraulic movable bath platform with teak 1100 LB/500 KG lifting capacitySwim platform chalksHydraulic tender garage with rotating aft seat and storage tubElectronic stern thruster

Generator

Onan 15 kW diesel

Stabilizer

Gyro stabilizer (1x Seakeeper 6)

Communication

Stereo Fusion 12V AM/FM with bluetooth module

Laundry

Washer and dryer in master cabin corridor

Anchor & Windlass

Galvanized anchor with galvanized chainAnchor rollerElectric anchor winch with helm station

Bow Thruster

Bow thruster electric

Equipment data sourced from manufacturer specifications, dealer brochures, and community contributions. Badge colors indicate confidence level.
